The little guy that really packs a punch! Designed in the same fashion as our heavy-duty soldering irons, these pencil-style irons are certainly not your average hobby iron. Referred to as production-ready, these irons repeatedly perform hard soldering applications, day in and day out. The combination of intense heat and unmatched durability yields a pencil iron that can proudly be called an American Beauty and makes a versatile tool in any maintenance and repair operation. (Stand Included)
Ni-Chrome Compression Wound Heating Elements are proven to be the most reliable heating element for maintaining soldering temperature in production environments.
Paragon Iron-Clad Lead-Free Soldering Iron Tips consistently outperform and outlast ordinary soldering iron tips many times over.
Plug-style tip design provides for superior heat transfer and easy cleaning.
Modular construction allows for easy replacement of consumable parts allowing for tools to last for generations.
The following products can be used as replacements for Model 3108-25 featured on this page:
The following products can be used as Accessories for Model 3108-25 featured on this page:
The following products are related (similar model but different specifications, etc.) to Model 3108-25 featured on this page:
Users of this product have stated that they use it for several jobs which include but are not limited to:
- Soldering daily and high volumes assemblies
- Melting zinc filler material for cosmetic repairs to soft metal sculptures
- Soldering electronic components
|Standard Tip Style||Chisel |
|Maximum Temperature||900 °F / 482°C|
|Stand included?||Yes |
|Available in a 220-240 VAC?||Not currently available in high voltage version |
|Tip Diameter||.125 in|
|Product Length||7.5 in / 19.05 cm|
|Product Width||1.125 in / 2.86 cm|
|Product Height||1.125 in / 2.86 cm|
|Product Weight||.55 lbs / 0.25 kg|
|Package Dimensions (Inches)||12 by 2-1/4 by 2-1/4 |
|Package Weight||1 lbs / 0.45 kg|
|Country of Origin||US |
|Harmonization Code:||8515.11.0000 |
|RoHS Compliant||Yes |
|IEC 60335-1, Edition 5.1, 2013-12||Yes |
|IEC 60335-2-45, Edition 3.2, 2012-01||Yes |
|WEEE Compliant||Yes |
|CE Certified||Yes |
|Understanding Tip Measurements||Explanation |
|Warranty Policy||Details |
|User Manual||User Manual |
