Model # V36GL3

60 Watt Industrial Grade Soldering Station

V36GL3
Testimonials

The work load here is heavy and the turnaround is as fast as I can make it, so unfortunately I have no pictures of any repair work completed using the V36GL3. I am mainly using Starboard polymer sheets for fabrication of parts and devices, however I also work with PVC and styrene. I am using the 60 watt industrial soldering station for both fabrication and repairs, using it to weld plastic pieces that were previously screwed together. Welding the plastic prevents the occurrence of breakage resulting in exposed screws, which is a common occurrence, and a big safety hazard. The folks I work with are all mentally and physically challenged, and many of them have poor motor skills. This can result in damage to their equipment due to things getting dropped or knocked off tables. Being able to fix broken plastic items is a big money saver, since I have to replace less things that I can now repair.

The plastic welding process is a lot like metal welding in that the strongest joint is achieved with the proper preparation and sufficient penetration.. The difference between metal and plastic welding is that with plastic you have to make sure you spend enough time 'under the iron' for both parts and the filler rod to all melt together, so its important not to rush the weld. This requires that your soldering iron has enough heat and the V36GL3 never lets me down, allowing me to perform top quality welds, time after time.

I'm also in charge of our fleet of 18 vehicles, which are buses and vans we use to transport our residents to and from our 13 group homes. These buses have molded PVC body panels, and I have been able to use the V36GL3 to repair minor collision damage on these parts, which is obviously way cheaper than replacing them.

I've also used the station for traditional electronic soldering, with excellent results. I had previously been using a cheap soldering pencil, which barely got hot enough to melt the solder. The V36GL3 heats up fast, and gives me control of the amount of heat for the job. I do repairs on electronic communication devices that our residents use, and being able to fix these things instead of paying the exorbitant replacement prices is great.

All in all, the V36GL3 was a very good investment, and has probably paid for itself already in the money I've saved from fixing instead of replacing. It is good to find a tool that does what it's supposed to do without any fuss.

Vincent C in Hummelstown, PA (Allegheny Valley School)

Thank you so much for the recommendation and for the new station. It works beautifully and stays hot forever! I just wanted to let you know I am very pleased with this iron and may order one for my wife as well.

Gene U. in Crystal City, TX
$225.00
QTY.   add to cart    ADD TO CART
Product Overview
American Beauty Industrial Soldering Stations offer the high thermal capacity of our production-ready pencil irons combined with amazing controllability. Industrial soldering stations are designed and built to perform under the most demanding production line conditions and withstand rugged usage in all maintenance and repair operations.

Each system comes complete with three different style soldering tips (Chisel, Diamond and Conical) maximizing the number of soldering jobs you can accomplish with one unit. Also included with the station is a detachable soldering iron holder and tip cleaner.



FEATURES AND BENEFITS

Solid-state voltage regulating device incorporated in each station permits tighter process control, longer heating element life and a reduction in damage resulting from excess thermal capacity.

Ni-Chrome Compression Wound Heating Elements are proven to be the most reliable heating element for maintaining soldering temperature in production environments.

Paragon Iron-Clad Lead-Free Soldering Iron Tips consistently outperform and outlast ordinary soldering iron tips many times over. Plug-style tip design provides for superior heat transfer and easy cleaning.

Compact, bench top unit, complete with detachable stand with dross collection sponge helps keep working tip clean and ready to accept solder.



REPLACEMENT PARTS

The following products can be used as replacements for Model V36GL3 featured on this page:

Model Product NamePrice
3937Replacement Item_Set Screws$14.50Add to Cart
482SReplacement Sponges for Industrial Stations$16.00Add to Cart
704Chisel Style Soldering Tip$15.50Add to Cart
709Diamond Style Soldering Tip$15.50Add to Cart
724Conical Style Soldering Tip$15.50Add to Cart
9012-60Replacement 60 Watt Compression-Wound Heating Element$54.00Add to Cart
V3-8058Solder Station Replacement Voltage Controller$42.00Add to Cart


ACCESSORIES

The following products can be used as Accessories for Model V36GL3 featured on this page:

Model Product NamePrice
485-8CDri-Wick Desoldering Braid in Thumb-Wheel Dispenser$7.25Add to Cart
701Turned Down Screwdriver Style Soldering Tip$15.50Add to Cart
703Turned Down Chisel Style Soldering Tip$15.50Add to Cart
714Turned Down Screwdriver Style Soldering Tip$15.50Add to Cart
715Semi Chisel Style Soldering Tip$15.50Add to Cart
716Turned Down Screwdriver Style Soldering Tip$15.50Add to Cart
720Screwdriver Style Soldering Tip$15.50Add to Cart
739Needle Point Conical Style Soldering Tip$15.50Add to Cart
749Oversized Chisel Style Soldering Tip$20.50Add to Cart
CS-ABKITSoldering Iron Maintenance Kit for 1/4" thru 9/8" Irons$34.00Add to Cart
HS-AHeat Sink - Micro Alligator Clip$12.50Add to Cart
HS-BHeat Sink - Alligator Clip$12.50Add to Cart
HS-CHeat Sink - Alligator Clip w. Barrel$12.50Add to Cart
SS-8Solder Sucker (3 oz)$12.50Add to Cart


SIMILAR PRODUCTS

The following products are related (similar model but different specifications, etc.) to Model V36GL3 featured on this page:

Model Product NamePrice
V36GM340 Watt Industrial Grade Soldering Station$220.00Add to Cart


APPLICATIONS

Users of this product have stated that they use it for several jobs which include but are not limited to:
  1. Soldering conductor of neon light bulb to create hermetic seal
  2. Soldering bussing ribbon
  3. Repairing electronics
  4. Soldering general use, including house, auto & hobby
  5. Teaching soldering in classroom setting
  6. Soldering artisan projects up to medium size.
  7. Welding 1/2" Starboard polymer for repairing and fabricating prosthetic equipment for the physically handicapped
  8. Soldering stained glass on professional level and volume
  9. Soldering wire connections for RC Trucks, Electric Bikes & Cars
Videos
Setting Up Your American Beauty Industrial Grade Solder Station
Routine maintenance for your Soldering station


TECHNICAL SPECIFICATIONS

Standard Tip StyleChisel,Diamond,Conical
Wattage60 watts
Maximum Temperature1050 °F / 566°C
Stand included?Yes
Available in a 220-240 VAC?Yes, available upon request
Tip Diameter.25 in
Product Length8.25 in / 20.96 cm
Product Width6.5 in / 16.51 cm
Product Height2.5 in / 6.35 cm
Package Weight4 lbs / 1.81 kg
Country of OriginUS
Harmonization Code:8515.11.0000
RoHS CompliantYes
IEC 60335-1, Edition 5.1, 2013-12Yes
IEC 60335-2-45, Edition 3.2, 2012-01Yes
WEEE CompliantYes
CE CertifiedYes
Understanding Tip MeasurementsExplanation
Warranty PolicyDetails
User ManualUser Manual
